1610030 - 3" CPVC True Union In-line T-21 Ball Valve, Socket x Socket

In stock
SKU: 1610030
Regular price $505.47

Free Shipping on all orders over $89

Most orders ship same day!

Order by phone or Questions? (800) 468 5997

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

3" CPVC/EPDM Socket T-21 Ball Valve

Features and Benefits

  • Pressure rated up to 230 psi (PVC, CPVC, PVDF)
  • Double O-ring seals on stem for an added protection.
  • Full bore, sizes ½" 2"
  • Full vacuum rated, all sizes
  • Blocks in two directions, upstream and downstream, leaving full pressure on the opposite end of the valve
  • Integrally molded ISO mounting pad for both manual and actuated operations
  • Integrally molded base pad to mount valves Securely or panel mounting
  • PTFEseats with elastomeric backing cushions ensure bubble-tight shut-offand a low fixed torque, while at the same time compensating for wear
  • True Union design for easier installation or repairs without expanding the pipe system
  • Built-in spanner wrench on the handle for valve disassembly and assembly
  • Two sets of end connectors (socket and threaded) included with all PVC and CPVC valves in sizes ½" 2"
  • CPVC threaded end connectors on sizes ½" 1" come with stainless steel reinforcing rings
  • NSF-61 Certified - Size: ½" - 4", Material: PVC, EPDM, FKM




DASAH00270
