Shoemaker 935FG - 24" x 14" Fixed 45 Degree Steel Blade Filter Grille
Regular price
$101.00
Free Shipping on all orders over $89
Most orders ship same day!
Order by phone or Questions? (800) 468 5997
Submittal SheetShoemaker 935FG - 24" x 14" Fixed 45 Degree Steel Blade Filter Grille
Features
- Roll formed steel blades fixed at 45 degrees, parallel to longest dimension
- Hinged removable extruded aluminum face frame with signature line marks
- Hinges parallel to longest side
- Face set in an outer filter grille frame
- Hand operated lever for easy filter access
- 4-way reversible door on square sizes
- 2-way reversible door on rectangular sizes
- Concealed mounting holes with mounting screws
- Holds up to a 1" filter (not included) with filter retention tabs (MODEL: 935FG1)
- Rust resistant pre-coat with durable powder finish
- Soft White
Specifications
- Duct Dimensions: 24" x 14"
- Overall Dimensions: 26-3/4" x 16-3/4"
