Home » Blower Motors » 51-104380-01 - 1/4 HP Blower Motor - 1 Phase - 4 Speed - 1075 RPM - 120V
Rheem

51-104380-01 - 1/4 HP Blower Motor - 1 Phase - 4 Speed - 1075 RPM - 120V

Out of stock
SKU: 51-104380-01
$174.95

Free Shipping on all orders over $89

Most orders ship same day!

Order by phone or Questions? (800) 468 5997

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Rheem 51-104380-01 - 1/4 HP Blower Motor - 1 Phase - 4 Speed - 1075 RPM - 120V

OEM replacements that may also be suitable for aftermarket retrofit in many other applications.

Features

  • HP: 1/4
  • Number of Speeds: 4
  • High Speed (RPM): 1075
  • Input Voltage (V): 120
  • Number of Phases: 1
  • Frequency (Hz): 60
  • Rotation Direction (OSE): CCW
  • Run Capacitor (uF/V): 7.5/370
  • FLA at 120V (A): 4.0
  • LRA at 120V (A): 8.1
  • Shaft Diameter (in.): 1/2
  • Motor Body Diameter (in.): 5-5/8
  • Keyed/Flat Shaft Length (in.): 4
  • Overall Shaft Length (in.): 4-1/2
  • Motor Body Length (in.): 4-11/16
  • Overall Motor Length (in.): 9-11/32
  • Mounting: Shell-band
  • Mounting: Shell-screw
  • Frame Size: 48
  • Bearing Type: Sleeve
  • Application: Blower
  • Drive Type: Direct Drive
  • Shipping Weight: 12.48 lbs

Where Used

  • R92PA
  • R95PA
  • R96PA
