The NIBCO check valve features a screw-in bonnet for accessibility to repair or replace parts. Swing check valves may be installed in horizontal positions (or vertical with flow moving up). Please refer to NIBCO technical data sheets, chemical resistance guides and catalogs for engineering and installation information. Choose NIBCO check valves for the most specified, versatile and economical valve option in commercial, mechanical and industrial applications. NIBCO check valves are backed by the NIBCO 5-year 125% limited warranty.

• 125 psi/8.6 bar saturated steam to 353 degree F/178 degree C
• 200 psi/13.8 bar non-shock cold working pressure
• Y-pattern
• Renewable PTFE disc
• Regrindable seat
• Class 125 solder end connections
• Use in U.S. drinking water applications is prohibited after January 3, 2014
• Conforms to MSS SP-139
• Potable Water Code: Not LL Comp not intend potable
• Classification: Quarter-Turn Sillcocks
• All Basic Material: Bronze
• Type of Valve: Check Valve
• Nominal Size: 1/2 in.
• Seat Seal Material:PTFE
• Valve End Connection Type: S -- Female Solder Cup
• Valve Multi Turn Bonnet Design: Screw-in Bonnet
• Valve Trim Package: PTFE Disc
• Valve Pressure Rating (CWP): 200 PSI / 13.8 Bar CWP
• Valve Pressure Rating (SWP): 125 PSI / 8.6 Bar SWP
• Turns Operations: Non-Manual

PVZ1K00840
